Name: Zolix DCS540 광학 초퍼 시스템 | Optical Chopper
Brand: 01. Spectroscopy

Description

DCS540 Optical Chopper System Features 0.01Hz resolution 1Hz~5KHz chopping frequency Standard TTL/COMS level input output 2.4inch LCD display Single Photoelectric encoder operating knob Specifications Frequency stability 250ppm/℃(typ.) Frequency drift 1% Frequency resolution 0.01Hz Operating Single Photoelectric encoder Operating temperature 10-40℃ Display Display 2.4 inch, 320*240 LCD Frequency display 6-digit Input Output |Input output BNC Input output compatibility standard TTL/COMS level Input voltage 0 ~ 5 V Input high level 3.6 V Input low level 0.4 V Min load resistance 500 Ω Interface RS232 to USB interfaces. All instrument functions can be controlled and read through USB interfaces General Power requirements Voltage 220 VAC 10% Frequency 50 Hz 0.2 Hz Power 30 W Dimensions Width 206 mm Depth 150 mm Height 70 mm

DCS540 광학 초퍼 시스템. 주요 특징: 0.01Hz 분해능, 1Hz~5kHz 초핑 주파수, 표준 TTL/CMOS 레벨 입출력, 2.4인치 LCD 디스플레이, 단일 광전 인코더 조작 노브.
