Finder Insight Pro_Raman Spectroscopy

Description

Application

■ Biomedicine

■ Polymer Chemistry

■ Environmental Science

■ Material Science

■ Geological Science

■ Cultural relic identification and restoration

■ Criminal investigation and drug identification
Characteristic

■ Small desktop Raman microscope with scientific research performance;

■ The spatial optical path is directly coupled to maximize the light collection efficiency;

■ Integrated built-in monitoring light path, visual sample selection and measurement, and automatic moving in and out of the monitoring light path;

■ The vertical light path is suitable for almost all sample shapes;

■ Optional horizontal light path accessories, suitable for measuring liquid glass bottles/tubes;

■ Optional 96-well test plate, automatic measurement operation;

■ The software contains multiple collection functions: single spectrum collection, continuous collection, interval collection, etc.;

■ The software contains a variety of data processing functions: fitting, smoothing, peak finding and peak area calculation, etc.;

■ The software can be optionally equipped with a database for comparison and measurement of unknown samples

Test Example:

Technical Information

Instruments	Finder Insight Pro
Model	FI785E10-Pro-M2	FI785E10W-Pro-M2	FI785E60-Pro-V2	FI785T-Pro	FI1064E20-Pro
Spectral range	150-2000cm⁻¹	150-3200cm⁻¹	150-2200cm⁻¹	150-2000cm⁻¹	200-2500cm⁻¹
Resolution	< 5cm⁻¹	< 10cm⁻¹	< 6cm⁻¹	< 5cm⁻¹	< 14cm⁻¹
Laser
Laser wavelength	785nm	785nm	785nm	785nm	1064nm
Laser Power	≥350mW; 0-100% Continuously adjustable	≥350mW; 0-100% Continuously adjustable	≥350mW; 0-100% Continuously adjustable	≥350mW; 0-100% Continuously adjustable	≥350mW; 0-100% Continuously adjustable
Laser line width	< 0.1nm	< 0.1nm	< 0.1nm	< 0.1nm	< 0.1nm
Detector
Type	TE cooling area	TE cooling area	TE cooling area	Room temperature NIR enhancement	TE refrigeration line array
	Back photosensitive CCD	Back photosensitive CCD	Back photosensitive CCD	Back photosensitive CCD	InGaAs array
Effective Pixels	2048*122	2048*122	2048*122	2048*64	512*1
Pixels size	12μm*12μm	12μm*12μm	12μm*12μm	12μm*12μm	25μm*500μm
Cooling temperature (typical value)	-10 °C	-10 °C	-10 °C	-10 °C	-20 °C
A/D	16-bit	16-bit	16-bit	16-bit	16-bit
Integral time	10ms-30s	10ms-30s	10ms-30s	10ms-30s	10ms-60s
Interface	USB 2.0	USB 2.0	USB 2.0	USB 2.0	USB 2.0
Accessories
Objective	Standard single lens 50X microscope objective	Standard single lens 50X microscope objective	Standard single lens 50X microscope objective	Standard single lens 50X microscope objective	Objective 50X microscope objective
Software	INScan-Lite	INScan-Lite	INScan-Lite	INScan-Lite	INScan-Lite
Power Supply
DC Adaptor input	12V~24V DC@2A	12V~24V DC@2A	12V~24V DC@2A	12V~24V DC@2A	12V~24V DC@2A
DC Adaptor output	100-240V AC 50-60Hz	100-240V AC 50-60Hz	100-240V AC 50-60Hz	100-240V AC 50-60Hz	100-240V AC 50-60Hz
Size (not including microscopy)	280450200mm	280450200mm	280450200mm	280450200mm	280450200mm
Weight (not including microscopy)	8kg	8kg	8kg	8kg	8kg

Instruments	Finder Insight Pro
Model	FI532E10-Pro-M2	FI532E10-H-Pro-M2	FI532E60-Pro-V2	FI532E60-H-Pro-V2
Spectral range	150-4400cm⁻¹	150-2800cm⁻¹	150-5000cm⁻¹	150-3200cm⁻¹
Resolution	< 10cm⁻¹	< 8cm⁻¹	< 10cm⁻¹	< 8cm⁻¹
Laser
Laser wavelength	532nm	532nm	532nm	532nm
Laser power	≥100mW; 0-100% Continuously adjustable	≥100mW; 0-100% Continuously adjustable	≥100mW; 0-100% Continuously adjustable	≥100mW; 0-100% Continuously adjustable
Laser line width	< 0.05nm	< 0.05nm	< 0.05nm	< 0.05nm
Detector
Type	TE cooling area Back photosensitive CCD	TE cooling area Back photosensitive CCD	TE cooling area Back photosensitive CCD	TE cooling area Back photosensitive CCD
Effective Pixels	2048*122	2048*122	2000*256	2000*256
Pixel size	12µm*12µm	12µm*12µm	15µm*15µm	15µm*15µm
Cooling temperature (typical value)	-10°C	-10°C	-60°C	-60°C
A/D	16-bit	16-bit	16-bit	16-bit
Integral time	10ms-30s	10ms-30s	10ms-60s	10ms-60s
Interface	USB 2.0	USB 2.0	USB 2.0	USB 2.0
Accessories
Objective	Standard single lens 50X microscope objective	Standard single lens 50X microscope objective	Standard single lens 50X microscope objective	Standard single lens 50X microscope objective
Software	INScan-Lite	INScan-Lite	INScan-Lite	INScan-Lite
Power Supply
DC Adaptor input	12V~24V DC@2A	12V~24V DC@2A	12V~24V DC@2A	12V~24V DC@2A
DC Adaptor output	100-240V AC 50-60Hz	100-240V AC 50-60Hz	100-240V AC 50-60Hz	100-240V AC 50-60Hz
Size (not including microscopy)	280*450*200mm	280*450*200mm	280*450*200mm	280*450*200mm
Weight (not including microscopy)	8kg	8kg	8kg	8kg
